Note: We reserve the right to make technical changes that serve progress at any time. Product images may differ from the original. Errors excepted.
| Position | Description | Article-No |
| 01 | SH OPERATING LEVER ALPHA_100 | Z056990-00010 |
| 02 | SH ROSETTE M37 X 1,5 / D:39,7X12 | Z009110-00010 |
| 04 | SH SCREW CONNECTION TO LINE 62 | Z009111-00000 |
| 05 | SH CARTRIDGE FOR HIGH PRESSURE | Z009200-00000 |
| 08 | SH PULL-OUT SPRAY F. KITCHEN MIXE | Z028804-00010 |
| 09 | SH HAND SHOWER FOR KITCHEN MIXER | Z028819-00010 |
| 10 | SH SCREW WITH STOP | Z000235-00000 |
| 13 | SH FLEXIBLE HOSE M8 X 1 – M15 X 1 | Z009074-00000 |
| 14 | SH FLEXIBLE HOSE M8 X 1 – 3/8" | Z009177-00000 |
| 19 | SH SCREW CONNECTION M34 X 1,5 | Z009196-00000 |
| 21 | SH LEAD WEIGHT | Z000287-00000 |
| Monolever-Kitchen mixer |
| Shaft screw connection kit |
| Lead weight |
| Assembly instruction |
| Care instruction |
| Certificate |
